01/ Product Introduction

The new series of 5X sand making machine set three kinds of crushing patterns in one which is the core equipment in construction mining metallurgy industry highways railways bridges hydropower mineral grinding areas and mechanism sand industry.

5X sand making equipment (centrifugal impact crusher) is widely used in a variety of metals and non-metallic minerals cement refractories abrasives glass raw materials construction aggregate sand mechanism metallurgy and other industries. The sand maker is uitable for crushing various mid-hard ores and rocks such as iron ore nonferrous metal ores silicon carbide bauxite quartz sand corundum perlite basalt and other types of high hardness materials.

02/ Product Features

Motor assembly
Standard high-performance vertical motor. Configure well-known brand engine stable performance quality assurance.
Alloy wear resistant block
Alloy wear-resistant block adoptes highly wear resistant and high temperature resistant materials in important U.S. industries and thus has a longer service life.
The New Impeller Design
Optimize material flow increase production by 30%. The crushed material is perfect in shape and does not require secondary shaping.
Feed Inlet Points Trays Design
Height can be adjusted to control the feed volume and different proportion of materials that are vertically into the impeller and scattered around of the impeller to adjust the particle size ratio.

03/ Technical Parameters

Model		5X7615	5X8522	5X9532	5X1145
Capacity(t/h)	Central feeding with circular cascade feeding	150-280	240-380	350-540	500-640
Capacity(t/h)	Fully central feeding	70-140	120-200	180-280	250-360
Max feeding size(mm)	Soft material	< 35	< 40	< 45	< 50
Max feeding size(mm)	Hard material	< 30	< 35	< 40	< 45
Rotation speed(r/min)		1700-1900	1500-1700	1300-1510	1100-1310
Double motor power(KW)		110-150	180-220	260-320	400-440
Overall dimension L×W×H(mm)		4100×2330×2300	4140×2500×2700	4560×2600×2900	5100×2790×3320
Weight(t)		12.1	14.8	18.6	27.5
Power		380V50Hz
Thin oil lubrication station	6
	Double oil oumps motor's power(KW)	2×0.31
	Safty Assurance	Double oil pumps assure enough oil supply; Switch off automatically without oil flow or oil pressure. Lower the temperature with cool water in summer raise the temperature with motor in winter.
	Overall dimension L×W×H (mm)	820×520×1270
	Power of oil Tank Heater(kw)	2
