01/ Product Introduction
Jaw crusher is a type of effective and energy conservation crushing machinery. Medium and large scale jaw crusher is main product of Vipeak and we have reached international level on designing and producing large scale crusher. Jaw crusher is main applied in all kinds of ore and big block material medium size crushing material's hardness should be less than 320Mpa coarse crushing and fine crushing are available. This series has a complete range of specifications feeding size could be 125mm～750mm it's the first choice of primary crushing. Jaw crusher could be widely used in mining smelting building material highway railway water conservancy and chemical industries.
02/ Product Features
Compact Structure and Unique Design
Unique jaw head structure and perfect seal lengthen bearing’s service life.Unique flywheel design reduces the shock of machine to guarantee stable operation.
Adjustment Device of Discharge Port
Spacer type discharge port adjustment device is very reliable wide range of adjusting flexibility of the machine is increased.
Energy-Efficient & Long Service Life
Deep crushing cavity no dead corner. Input size range and capacity are increased; big crushing radio even final product new oil-way design can match up with oil pump easier and effective operation.
Mono-Block Cast & High Safety Factor
Adopting mono-block cast and and new assembly technology could make it match up with rack perfectly radial strength is increased.03/ Technical Parameters
| Model | C6X110 | C6X125 | C6X145 | C6X160 | C6X200 | |
| Size of Feed Opening(mm) | 1100 | 1250 | 1450 | 1600 | 2000 | |
| Size of feed openning width(mm) | 850 | 950 | 1100 | 1200 | 1500 | |
|
Power(kw)
|
160 | 160 | 200 | 250 | 400 | |
|
Rotate speed(rpm)
|
230 | 220 | 220 | 220 | 200 | |
| Product size(mm) |
Tight
side discharge
opening(mm)
|
T/H
|
T/H | T/H | T/H | T/H |
| 0-105 | 70 | |||||
| 0-120 | 80 | 160-240 | ||||
| 0-135 | 90 | 180-260 | ||||
| 0-150 | 100 | 200-280 | 240-340 | |||
| 0-185 | 125 | 250-360 | 280-410 | 320-470 | ||
| 0-225 | 150 | 300-430 | 340-480 | 370-550 | 420-610 | |
| 0-260 | 175 | 340-490 | 370-550 | 430-630 | 470-700 | 620-890 |
| 0-300 | 200 | 380-550 | 420-620 | 480-710 | 530-790 | 690-1000 |
| 0-340 | 225 | 470-690 | 540-790 | 590-880 | 770-1100 | |
| 0-375 | 250 | 520-760 | 600-870 | 650-970 | 850-1200 | |
| 0-410 | 275 | 660-950 | 700-1060 | 930-1300 | ||
| 0-450 | 300 | 750-1100 | 1000-1500 | |||
